TECH SPECS
Pro Mini Datasheet
Capacity
4TB & 8TB*
Connectivity
40Gb USB4/Thunderbolt USB-C port
Universal Connectivity for USB2, USB3, USB4 and Thunderbolt
Cables
0.3m 40Gb included. 1m, 2m or 5m 40Gb available.
OS Support
macOS 13.0+ (Ventura, Sonoma, Sequoia, Tahoe)
Windows: 10 version 21H2, 11 version 22H2+
Linux: Ubuntu 22.04+ (running kernel 6.8-generic or later)
Power
7.5W or 15W USB-PD bus power
Dimensions
5.16” × 2.72” × 0.51”, 8.15oz
131mm x 69mm x 13mm, 231g
Features
Portable Bus-Powered SSD
Universal USB4® and Thunderbolt™️ Connectivity
Customizable Digital Label
Solid-State Cooling powered by AirJet®
Works with macOS, Windows, and Linux
Multiple Filesystem Containers
Machined Aluminum Chassis
Device Passkeys with NFC Tap to Unlock
XTS-AES-256 Encryption with Hardware Secure Enclave
Transactional RAID-6 Data Protection
Data Checksums and Self-Healing
Automatic Fault Management and RAID resilvering
Find My Tracking for Apple and Google Find My Networks
Fleet Management with iodyne Cloud subscription
Remote Transfer Monitoring with iodyne iOS App
Workflow Metadata linked to iodyne Cloud Projects
Accessories
3x Color ID Tags included.
More available on our store:
Cable Clamp
1x Hard Case
4x Hard Case
Lanyard Strap
Protocols
Warranty
One year standard. Extended to three years at no charge upon registering your device with an iodyne Cloud account.
Total Bytes Written
Maximum Available Capacity
4T
8T
4TB
8TB
Device Protection
IP54 Dust and Water Resistant***
36″ Drop Resistant***
Operating Temperatures
System: 50° to 95°F (10° to 35°C)
Storage: -13° to 113°F (-25° to 45°C)
Safety Standards
FCC ID: 2BSC8-52-1-1
IC: 34628-520101
IEC 62368-1:2014
EN 62479:2010 and BS EN 62479:2010
BIS Export Compliant ECCN 5A992 (US)
Environmental Standards
RoHS compliant
REACH compliant 100%
WEEE Directive 2012/19/EU
Recycled pulp packaging
EMC Standards
US: FCC 47 CFR Part 15 Subpart B
US EN 300 328 V2.2.2 (2019-07)
US CNS 15936 (2016)
Canada: ICES-003 Issue 6:2016
European Union:
EN 55032:2015 + AC:2016
EN 55035:2017
EN 61000-3-2:2014
EN 61000-3-3:2013
Japan: VCCI-CISPR 32:2016
MDA (Singapore) R2508015-IMDA
MIC (Japan) R2508015-MIC
Australia & New Zealand NCC LP0002-2024
Australia & New Zealand CISPR 32:2015+AMD1:2020
* Data quantities refer to International System of Units (SI) decimal prefixes: 1MB = 106 bytes, 1GB = 109 bytes, and 1TB = 1012 bytes, and one byte is a data element that is eight bits in size as defined in ISQ/IEC 80000.
** Additional capacity used for error correcting codes, metadata, and defect redundancies not included. Metadata, metadata RAID parity, and OS-specific formatting such as partition tables and boot partitions may reduce capacity.
*** See Warranty for additional details regarding protection from dust, water and drop damage.
